Lincoln Electric Ranger® 305 LPG Engine Driven Welder (Kohler®) Ready-Pak® #K5168-1

Lincoln Ranger® 305 LPG Engine Driven Welder (Kohler®) Ready-Pak® #K5168-1

ADVANCED. SPECIALIZED. POWERFUL.

The Lincoln Electric Ranger 305 LPG engine-driven welder is one of the highest-quality specialty machines on the market. Built and designed by the experts at Lincoln Electric, it is capable of TIG, MIG, gouging, stick, and flux-cored SS/GS welding processes. It has a rugged and heavy-duty frame and full metal casing on wheels for added mobility. Generate up to 9,000 watts of continuous power with the liquid petroleum Kohler 25 HP 2-cylinder air-cooled engine. It is loaded with exclusive features, making it perfect for applications in construction, structural welding, and much more.

FOR SPECIALIZED ENVIRONMENTS

Choose the Ranger 305 LPG welder/generator for those environments where gasoline and diesel emissions are not acceptable. Includes a liquid propane gas supply hose with coupler for easy connection to the liquid draw outlet of an LP-gas cylinder. The 10,000-watt peak single-phase AC generator powers motor starting, tools and inverter welders for extended range and process capability.

FEATURES OF THE RANGER® 305 LPG

• Top-of-the-line Kohler® overhead valve (OHV) 25 HP Command® LPG engine
• Digital weld meters monitor actual welding output
• Built-in “hot” start for easier starts and restrikes

MULTI-PROCESS WELDING

• Excellent DC multi-process welding for general purpose stick, downhill pipe (stick), TIG, cored-wire and MIG (CO2 and mixed gas).
• It’s the only compact LPG welder in North America rated at 25V for 300 amps of stick or CV welding.
• CV wire welding with up to 5/64 in. (2.0 mm) diameter electrodes.

DIGITAL WELD METERS

• Digital weld meters for amps and volts makes it easy to precisely pre-set your procedures and monitor actual welding output.

SUPERIOR ARC PERFORMANCE

• Lincoln Electric Chopper Technology® provides easy starts, a smooth arc, low spatter and excellent bead appearance.

10,000 WATTS PEAK SINGLE-PHASE AC GENERATOR POWER

• 10,000 watts peak for motor starting.
• 9,000 watts continuous for high capacity needs such as a back-up generator, powering a Lincoln Electric Invertec® inverter welder. Also can be used for lights, a grinder or other power tools.
• AC generator voltage is constant at 120V or 240V at any weld dial setting.

RUGGED RELIABILITY

• Welding and AC Generator Outputs rated at 104ºF (40ºC).

25 HP KOHLER® LPG ENGINE

• LPG (Liquid Propane Gas) engine has plenty of horsepower.

Order a Lincoln Electric Ready-Pak and get everything you need in one preassembled package. The package consists of: K2937-1 Ranger 305 LPG K1770-2 Factory Undercarriage (Pneumatic) K1745-2 LPG Tank Holder in one preassembled package

WHAT’S INCLUDED

• K2937-1 Ranger 305 LPG K1770-2
• Factory Undercarriage (Pneumatic) K1745-2
• LPG Tank Holder in one preassembled package
